Hose Silicone Reinforced Ø10 Blue
Hose Silicone Reinforced Ø10 Blue
15m Coil
Material: Silicone
Reinforcement: 1-Ply Nylonfiber
Outer diameter: 18 mm
Inside diameter: 10 mm
Bend radius: 5 x ID
Standard wall thickness: .140"/.170"
Working Pressure: 1/3 of Burst Pressure
Bursting Pressure PSI:
SAE J20 R1: 250
TMC: 125
Actual Burst Pressure: PSI: 310
Working Pressure: 1/3 of Burst Pressure
Withstands temperatures from:
-54°C to +177°C
If you are interested in longer or shorter lengths, contact us by e-mail or by phone.
Item code: FLX5526-10-15M
